Case Study / Residential Project

How Danny S. from MA Got His
Site Plan for a Construction Permit

Danny S., a new residential client from Georgetown, Massachusetts needed a detailed site plan for a building permit application.

His project involved constructing a 10×15 single-story addition on the left rear side of his home.

An existing deck in that area was scheduled for removal, and the local building department required both the deck removal and proposed addition to be clearly identified on the site plan.

How Danny Got Started

Danny selected our Gold Package Site Plan and requested delivery in PDF, JPG, DWG, and DXF formats. He chose a 12-hour turnaround time and provided a technical drawing showing the existing house, the proposed mudroom addition, and several key measurements.

Because the Gold Package includes our most comprehensive drafting features, the project also incorporated a Vicinity Map, Topographical Lines, and Topographical Contour Lines.

Get Your Construction Site Plan

Address Only – No Site Visit Required

Danny S. “Very simple site to use. I explained what I needed. Within hours I had what I needed with a polite email pretty much saying if I need anything else or anything adjusted to simply let them know. Extremely happy I found this company!“

How We Drafted Danny's Construction Permit Site Plan

Using the technical drawing and project notes provided, our CAD team created a detailed site plan showing the existing house, the deck scheduled for removal, and the new proposed addition with required setback measurements.

We completed the project in just 8 hours, faster than the 12-hour turnaround Danny selected.

Danny’s Gold Site Plan drawing incuded all necessary information like:

Property Lines
Primary Structure
North Arrow
Parcel ID
Landscape
Lawn
Swimming Pool

Lot dimensions
Scale, Roofline
Fence, Trees
Sidewalks
Driveway
Paths, Shrubs
Parking Spaces

Measurements Between Major Features
Accessory Structures
Well and septic system
Additional new structures
Topographic Contour Lines
Vicinity Map

REVISIONS

Danny requested three revisions, which our team completed promptly and at no additional cost.

These updates helped refine the placement details and ensure the plan matched the project’s final requirements.

Result: Construction Permit Site Plan Ready in Georgetown, MA

This project demonstrates how a detailed site plan can simplify the permitting process for residential additions.

Danny appreciated the quick turnaround, clear communication, and attention to detail throughout the project.

The biggest advantage was having both the existing deck removal and proposed addition accurately represented on a single plan, giving him everything needed for a smooth permit submission.

What Danny said about our plan

Very simple site to use. I explained what I needed. Within hours I had what I needed with a polite email pretty much saying if I need anything else or anything adjusted to simply let them know. Extremely happy I found this company!
