Austin M., a repeat contractor from Summerville, South Carolina, needed a detailed site plan for a metal accessory structure permit.
The project involved a new steel building measuring 50 feet wide by 60 feet long, with a 16-foot eave height and a 3:12 roof pitch.
The permitting department had requested revisions to a previously submitted plan, so Austin needed an updated site plan that reflected the new requirements.
Austin selected our Gold Package Site Plan and requested delivery in PDF, JPG, and DWG formats.
He chose a 12-hour turnaround time and provided a satellite image showing the property along with the proposed location of the new building.
He also shared the updated building dimensions and revision requirements, giving our team the information needed to prepare a permit-ready site plan.
Address Only – No Site Visit Required
Excellent 4.9/5 based on 947 reviews
Austin M. “Very easy to work with and great results with quick turn around times. Michael is the best!”
Using the satellite image and project details, our CAD designers prepared a detailed site plan showing the proposed metal structure and its relationship to existing property features.
The plan was completed in just 8 hours, faster than the selected turnaround time, and delivered in all requested file formats.
Austin’s Gold Site Plan drawing incuded all necessary information like:
REVISIONS
Austin requested three revisions, which our team completed promptly at no additional cost.
The updates reflected changes requested during the permit review process and ensured the final plan met all project requirements.
This project demonstrates how quickly an updated site plan can be prepared, even when permit revisions are involved.
Austin appreciated the responsiveness of our team and the accuracy of the final draft.
The biggest advantage was having a revised, detailed site plan delivered ahead of schedule, helping keep the steel building project on track and minimizing delays during the permitting process.
