Case Study / Residential Project

How Ashley B. From Missouri Got Her Approved
Site Plan for a New House Building Permit

Ashley B., a new residential client from Kansas City, Missouri, needed a detailed site plan for a new house building permit.

She planned to construct a 14′ x 40′ small home on a concrete slab within a subdivision and needed a professionally drafted site plan to support her permit application.

How Ashley Got Started

Ashley selected our Gold Package Site Plan and requested delivery in PDF, JPG, and DWG formats.

She chose a 12-hour turnaround time and provided a satellite image of the property with the proposed construction area clearly marked.

She explained that the new home would measure 14 feet by 40 feet and be built on a concrete slab of approximately 1,000 square feet, giving our team a clear understanding of the project’s requirements.

Get Your New House Building Permit Site Plan Approved

Address Only – No Site Visit Required

Ashley B. “Quick turn around, excellent work, revisions made very quickly. I’m very happy!”

How We Drafted Ashley's New House Building Permit Site Plan

Using Ashley’s satellite image and project details, our CAD designers created a non-certified site plan, accepted by most townships, showing the proposed home and all required property features.

The plan was completed in just 7 hours, faster than the turnaround time Ashley selected, and delivered in all requested file formats.

The detailed layout provided a clear representation of the property and the proposed home location, helping prepare the project for the permitting process.

Ashley’s Gold Site Plan drawing incuded all necessary information like:

Property Lines
Primary Structure
North Arrow
Parcel ID
Landscape
Lawn
Swimming Pool

Lot dimensions
Scale, Roofline
Fence, Trees
Sidewalks
Driveway
Paths, Shrubs
Parking Spaces

Measurements Between Major Features
Accessory Structures
Well and septic system
Additional new structures
Topographic Contour Lines
Vicinity Map

REVISIONS

Ashley requested five revisions during the project.

These updates mainly focused on refining placement details and ensuring the proposed structure matched her vision.

Our team completed every revision quickly and at no additional cost.

Sketch for a New House Building Permit in MO

Result: New House Building Permit Site Plan Ready in Kansas City, MO

This project demonstrates how a detailed site plan can simplify the planning phase of a new home construction project.

Ashley appreciated the responsiveness of our team, the accuracy of the drafts, and our willingness to make multiple revisions until everything was exactly right.

The biggest advantage of this project was the close collaboration between our designers and the client.

By combining clear communication with fast turnaround times, we delivered a site plan that gave Ashley confidence to proceed with her new home project.
