Case Study / Residential

How a Homeowner from Lake Worth, Florida Got Their
Site Plan Approved for a Driveway Permit

Larry, a new client from Lake Worth, Florida, got in touch with our team needing a site plan for a residential driveway permit.

His goal was to replace an existing asphalt driveway with a new concrete one, and to do that, he needed a detailed, permit-ready site plan that met all local planning requirements.

Order:

Larry selected our Medium Package Site Plan, with a custom paper size of 11×17 inches, and opted for 12-hour delivery.

He shared two drawings clearly outlining his vision and the necessary updates for the site plan, including the removal of asphalt and the addition of the new concrete driveway.

OUR SOLUTION:

Our design team quickly reviewed Larry’s drawings and began crafting a custom, non-certified site plan that incorporated all requested features.

We ensured the plan met all planning requirements for a driveway permit and delivered it in PDF format within 12 hours—just as requested.

No site visit was required, which allowed us to keep the process fast and efficient.

Larry’s Medium Package Site Plan drawing incuded all necessary information like:

Property Lines
Primary Structure
North Arrow
Parcel ID

Lot dimensions
Scale, Roofline
Fence, Trees
Sidewalks

Measurements Between Major Features
Swimming Pool
Accessory Structures
Driveway

REVISIONS

Larry requested one revision, which our team handled promptly and with care.

As always, we implemented the update at no extra charge, ensuring Larry’s complete satisfaction.

SUMMARY

This project shows the power of clear communication, quick turnaround, and expert drafting.

Larry received a high-quality, permit-ready site plan with everything his project required—on time, on spec, and with no stress.

We’re proud to have helped Larry move one step closer to his new driveway. The seamless collaboration and clear requirements made this project smooth and successful—just the way we like it.
