Lori, a new client from Seattle, Washington, needed a precise and compliant site plan to obtain a permit for adding a 10’x15′ shed in the northeast rear corner of her residential property.
With a tight schedule and clear zoning requirements—5′ rear and side yard setbacks—she was looking for fast, reliable service.
Order:
Lori chose our Premium Site Plan Package.
She requested the plan to be delivered within 12 hours, in PDF and DWG formats, and sized 11×17 inches.
Though she didn’t provide any reference files, she included a short note explaining where the new shed should be located.
OUR SOLUTION:
With no supporting documents other than the note, our CAD team got to work immediately.
We used GIS and zoning data to design a precise, compliant layout.
We clearly marked the proposed shed and setbacks for permit approval and delivered the completed plan in both requested formats — on time, within 12 hours.
The site plan we created included:
REVISIONS
Lori requested four revisions to fine-tune shed placement and clarify a few measurements.
Each was handled quickly, patiently, and accurately by our team — ensuring a stress-free process.
SUMMARY
This case study showcases the speed, flexibility, and quality of our service.
Lori’s shed project moved forward seamlessly with a permit-ready plan delivered in just 12 hours — despite starting with no files.
Our designers’ dedication ensured every revision was handled with care, helping Lori feel supported and confident throughout the process.
