Site Plan for Septic Permit

In most counties yes – for new systems, replacements, expansions, or repairs. Check your local health department and HOA before ordering.

Scaled property lines, septic tank with house sewer connection, drainfield/leach field (or mound) with distribution box & laterals, the reserve/replacement area, setbacks to wells, water features, buildings & property lines, easements/utilities, and optional slope/drainage arrows.

No. We provide the site plan. If your county requires an engineered design or perc/soil test, those are obtained separately—we’ll annotate their results on the plan.

Yes—if your designer/installer specifies them. We can label pump/pressure-dosing components and mound footprints/notes provided to us.

Yes. We can add an abandonment note for existing tanks/fields per your county’s instructions and show the new system in relation to the old.

Our non-certified site plans are accepted by most cities & HOAs. Requirements can vary, so please check with your local office first.

Our standard delivery is within 24 h, you can choose rush options 6h or 12 h

We include unlimited revisions until approval or money back.

You’ll receive a PDF ready for online portals or print. DWG & JPG are available on request.

In many cities, the terms are used interchangeably. We draft a scaled plan that matches typical permit/HOA requirements, and we revise if your reviewer requests changes.

Property address, system type (new, replacement, or expansion), tank size & location (if known), drainfield/leach field or mound dimensions and location, well location (if any), setback notes from your health department, and your installer’s or engineer’s layout if available.
